01 / P·V
Pressure Vessels
Heavy-wall reactors, separators, columns, and accumulators built to ASME Section VIII Division 1, with U stamping.
CodeASME VIII Div. 1 / 2
Diameterup to 6,000 mm Ø
Weightup to 180 MT
Materialup to 120 mm thick
Workshop Active · Cikarang, ID
N° 01 / 06
ASME U · S Certified Manufacturer
Pressure vessels
engineered to
withstand.
PT SK Metalindo designs and fabricates ASME-coded pressure vessels, storage tanks, heat exchangers, expansion joints, and gaskets for energy, petrochemical, and process industries across Southeast Asia and beyond.
17+
Years in service
1,200+
Vessels delivered
U·S
ASME stamps held
14×
Countries served
Oil & Gas◆Petrochemical◆Power Generation◆LNG & Cryogenics◆Pulp & Paper◆Fertilizer◆Geothermal◆Mining & Minerals◆Oil & Gas◆Petrochemical◆Power Generation◆LNG & Cryogenics◆Pulp & Paper◆Fertilizer◆Geothermal◆Mining & Minerals◆Oil & Gas◆Petrochemical◆Power Generation◆LNG & Cryogenics◆Pulp & Paper◆Fertilizer◆Geothermal◆Mining & Minerals◆
Capabilities · 01
Four disciplines.
One workshop.
Every product leaves our Cikarang facility with full material traceability, third-party witnessed testing, and documentation aligned to the client's jurisdictional code. No subcontracted welding. No compromise on WPS.
02 / S·T
Storage Tanks
Field-erected atmospheric and low-pressure tanks for crude, refined products, water, and chemicals — API 650 and 620.
CodeAPI 650 / 620
Volumeup to 50,000 m³
RoofFixed · IFR · EFR
ServiceHydrocarbons + water
03 / H·E
Heat Exchangers
Shell-and-tube and double-pipe exchangers per ASME VIII and TEMA Class R, C, and B for refining, gas, and petrochemicals.
CodeASME VIII + TEMA
TypeShell-tube · Double-pipe
Surfaceup to 2,500 m²
MaterialCS · SS · Duplex · Ti
04 / E·J
Expansion Joints
Metallic, fabric, and rubber expansion joints engineered to EJMA and ASME B31.3 for high-temperature ducts and process piping.
CodeEJMA · ASME B31.3
TypeMetallic · Fabric · Rubber
SizeDN 25 — DN 4,000
Service≤ 1,100°C · ≤ 40 bar
Credentials · 02
Code-stamped.
Audit-ready.
Always.
ASME
Pressure Vessels
ASME VIII Div. 1
ASME
Power Boilers
ASME Section I
Witnessed Testing
Hydrotest, PMI, and final inspections under third-party and client surveillance — Lloyd's, BV, ABS, SGS, TÜV.
Full NDE Suite
RT, UT, PT, MT, and phased-array UT performed in-house by Level II/III certified inspectors.
Material Traceability
Heat-number tracking from mill certificates through to as-built dossiers — every weld, every plate, every joint.
Selected Work · 03
A selection
of jobs done.
001
Power · Geothermal
Patuha-2 Geothermal
West Java, ID
Two-stage steam scrubbers and atmospheric flash tanks, 4,500 mm Ø × 18,000 mm T/T, SS316L for chloride service.
Qty4 units
Weight142 MT ea
Year2025
002
Power · Geothermal
Muara Laboh-2 (Stage 2)
Sumatra, ID
Scrubber, atmospheric flash tank, and piping for Sumitomo / IKPT / Wasa Mitra consortium. ASCE 7-16 seismic, API-650 design.
ClientSupreme Energy
Weight168 MT
Year2024–26
003
Oil & Gas · Upstream
Production Separator Package
Kalimantan, ID
Three-phase horizontal separator, 3,200 mm Ø × 12,000 mm T/L–T/L, SA-516 Gr.70 with 3 mm Alloy 625 weld overlay.
Qty3
Weight108 MT ea
Year2024
004
Refinery · Hot-Gas
FCCU Universal Expansion Joints
Jawa Barat
DN 2,800 universal tied joints for flue-gas ducting, Incoloy 800H bellows, 720°C operating.
Qty6
MaterialIncoloy 800H
Year2023
005
Storage · Field-Erected
Crude Oil Tank Farm
Sumatra, ID
API 650 external floating roof, 55 m Ø × 18 m height, 42,000 m³ ea.
Qty4 tanks
Volume168,000 m³
Year2022
006
Fertilizer
Urea Synthesis Reactor
Kalimantan Timur
ASME VIII Div. 1, SA-336 F22V with 25Cr-22Ni-2Mo overlay, NACE MR0175.
DiameterØ 2,400 mm
Weight176 MT
Year2021
Voices · 05
What
our clients
say.
[REPLACE WITH REAL CLIENT QUOTE — strong line about delivery discipline, code adherence, and on-time hand-over for a large geothermal package.]
SE
[Client Name]Project Director · Supreme Energy
[REPLACE WITH REAL CLIENT QUOTE — quality of welding, NDE documentation, and inspection readiness for a refinery expansion project.]
PT
[Client Name]Engineering Manager · Pertamina
[REPLACE WITH REAL CLIENT QUOTE — capability with exotic materials and tight schedule for an upstream separator package in Kalimantan.]
IK
[Client Name]Procurement Lead · IKPT
Live testimonials replace placeholders before launch.
Inquiry · 05
Have a datasheet?
Send it.
Send drawings, P&IDs, or written specifications. Our engineering desk reviews every inquiry and returns a budget figure or technical clarification within 24 hours.
- WorkshopCikarang Timur, West Java, Indonesia
- Commercial emailmarketing.bdm1@skmetalindo.com
- Engineering direct+62 (0) 267 — 000 0000
Form / RFQ-01 · Request for Quotation
Rev. 01 · 2026
Submissions routed to the senior engineering desk.
